Weiguang YZF3206 Refrigeration Fan Motor with 124mm Blade – 220–240V

Weiguang YZF3206 Refrigeration Fan Motor – 220–240V

The Weiguang YZF3206 is a single-phase shaded-pole fan motor for refrigeration equipment, including refrigerators, refrigerated cabinets and supermarket cooling applications.

Operating on a 220–240V, 50Hz supply, it has a listed speed of 2400 rpm and an input power of 18W. The manufacturer specifies performance with a 124mm fan blade, delivering an airflow of 124m³/h.

Suitable for ambient temperatures from −25°C to +50°C, the YZF3206 features Class B insulation and impedance protection.

Check mounting dimensions, shaft arrangement, rotation and airflow direction against the original motor before ordering.

Manufacturer: Weiguang
Manufacturer Part Number: YZF3206
Motor type: Shaded-pole
Supply: 220–240V, single-phase
Frequency: 50Hz
Input power: 18W
Current: 0.14A
Speed: 2400 rpm
Supplied blade diameter: 124mm
Listed airflow: 124m³/h
Ambient temperature: −25°C to +50°C
Insulation class: B
Motor protection: Impedance protection
Supplied with: 124mm fan blade
